上一篇文章介绍了 ingress vhost这个annotation的使用，趁热打铁我们一口气介绍 9 个常用的annotation。
1、ingress class
如果一个k8s 集群里面部署多个ingress controller的时候，如果配置ingress 希望指定到某个ingress controller的时候，ingress claas就发挥巨大作用了。
一方面在controller启动的时候需要通过参数指定ingress class
- –ingress-class=ngx-ds
另一方面，在创建ingress的时候，通过annotation指定ingress class，如下所示
- apiVersion:extensions/v1beta1
- kind:Ingress
- metadata:
- name:other-ngx-k8s
- namespace:other-ngx
- annotations:
- kubernetes.io/ingress.class:"ngx-ds"
- spec:
- rules:
- -host:other-ngx-k8s.demo.com.cn
- http:
- paths:
- -path:/
- backend:
- serviceName:other-ngx-k8s-ngx-svc
- servicePort:9001
2、 强制https
- apiVersion:networking.k8s.io/v1beta1
- kind:Ingress
- metadata:
- name:test-ingress
- annotations:
- nginx.ingress.kubernetes.io/rewrite-target:/
- nginx.ingress.kubernetes.io/force-ssl-redirect:"true"
- nginx.ingress.kubernetes.io/ssl-redirect:"true"
- nginx.ingress.kubernetes.io/preserve-trailing-slash:"true"
- spec:
- rules:
- -http:
- paths:
- -path:/testpath
- backend:
- serviceName:test
- servicePort:80
3、请求超时
- apiVersion:networking.k8s.io/v1beta1
- kind:Ingress
- metadata:
- name:cafe-ingress-with-annotations
- annotations:
- nginx.org/proxy-connect-timeout:"30s"
- nginx.org/proxy-read-timeout:"20s"
- spec:
- rules:
- -host:cafe.example.com
- http:
- paths:
- -path:/tea
- backend:
- serviceName:tea-svc
- servicePort:80
- -path:/coffee
- backend:
- serviceName:coffee-svc
- servicePort:80
4、跨域访问
我们经常将nginx作为api的网关，支持跨域必不可少。通过
- apiVersion:networking.k8s.io/v1beta1
- kind:Ingress
- metadata:
- name:test-ingress
- annotations:
- nginx.ingress.kubernetes.io/enable-cors:"true"
- nginx.ingress.kubernetes.io/cors-allow-methods:"PUT,GET,POST,OPTIONS"
- nginx.ingress.kubernetes.io/cors-allow-headers:"X-Forwarded-For,X-app123-XPTO"
- nginx.ingress.kubernetes.io/cors-expose-headers:"*,X-CustomResponseHeader"
- nginx.ingress.kubernetes.io/cors-max-age:600
- nginx.ingress.kubernetes.io/cors-allow-credentials:"false"
- spec:
- rules:
- -http:
- paths:
- -path:/testpath
- backend:
- serviceName:test
- servicePort:80
5、限流
限流也经常使用，通过 rps 限制每秒请求数，rpm 限制每分钟请求数，connections限制连接数。
- apiVersion:networking.k8s.io/v1beta1
- kind:Ingress
- metadata:
- name:test-ingress
- annotations:
- nginx.ingress.kubernetes.io/limit-rps:"5"
- nginx.ingress.kubernetes.io/limit-rpm:"300"
- nginx.ingress.kubernetes.io/limit-connections:"10"
- spec:
- rules:
- -http:
- paths:
- -path:/testpath
- backend:
- serviceName:test
- servicePort:80
6、最大body
这个主要是针对外部请求，防止将流量打满，proxy-body-size 设置最大请求 body，如果超过则会返回 413 请求错误。
- apiVersion:networking.k8s.io/v1beta1
- kind:Ingress
- metadata:
- name:test-ingress
- annotations:
- nginx.ingress.kubernetes.io/proxy-body-size:8m
- spec:
- rules:
- -http:
- paths:
- -path:/testpath
- backend:
- serviceName:test
7、客户端白名单
这个主要是用于安全限制，只允许特定的客户端请求，但由于现在网络中NAT的广泛应用，这个参数使用的场景比较有限。
- apiVersion:networking.k8s.io/v1beta1
- kind:Ingress
- metadata:
- name:test-ingress
- annotations:
- ingress.kubernetes.io/whitelist-source-range:"10.0.0.0/24,172.10.0.1"
- spec:
- rules:
- -http:
- paths:
- -path:/testpath
- backend:
- serviceName:test
8、默认服务
这个经常使用，当客户端请求一个不存在的path的时候，我们不希望返回 404 ，跳转到一个默认的服务上。
- apiVersion:networking.k8s.io/v1beta1
- kind:Ingress
- metadata:
- name:test-ingress
- annotations:
- nginx.ingress.kubernetes.io/default-backend:<svcname>
- spec:
- rules:
- -http:
- paths:
- -path:/testpath
- backend:
- serviceName:test
9、access log开关
nginx ingress 默认是开启access log的，如果你想关闭，可以通过将
- apiVersion:networking.k8s.io/v1beta1
- kind:Ingress
- metadata:
- name:test-ingress
- annotations:
- nginx.ingress.kubernetes.io/enable-access-log:"false"
- spec:
- rules:
- -http:
- paths:
- -path:/testpath
- backend:
- serviceName:test
